- Auto
Level Rec start
- Auto
Track Increment
- Stereo/Mono
recording (74/148 min.)
- UTOC
Writing
- The
U-TOC recording method is selectable. (Manual/Auto is switched according
to the preset U-TOC mode.)
- Using
CUE Signals to make searches
- Editing
1) Basic Editing
- DIVIDE, ERASE TRACK/DISC, COMBINE, MOVE, TRACK/DISC NAME
2) Erase any A-B section.
3) A-B section can be inserted into any track.
4) Cue signals also can be edited.
- Undo
function
- SCMS
: Recording is possible without reception of the copy defeat restriction.
Writing of the copy defeat code is selectable.
- Easy
operations from IBM-PC compatible keyboard
- Hot
Start unit ACD-26HM (Option)
- 19
inch Rack Mountable (Height: 3U)
- Large
FL Display, Illuminated Rubber Button
- Track
Search Select knob (Easy track selection)
- Jog/Shuttle
Wheel
- Program
Play
- Play
mode & Finish mode
- Auto
Cue
- End
Monitor
- End
Of Message (EOM)
- Pitch
Control (+-9.9 %, 0.1 % step)
- Instant
Start
- Rich
Array of External Control Terminals
- Sampling
Rate Convertor unit ACD 25-FSM (Option)
- External Sync
unit ACD-27MS (Option)
Dimensions : 483
(W) x 132 (H) x 297 (D) mm
Weight : 6.9 kg
|
